| Bezeichnung | Wert | Einheit |
|---|---|---|
| Druckverhältnis | 20/1 | |
| Maximaler Materialdruck | 120 (1740) | bar (psi) |
| Maximaler Lufteingangsdruck | 6 (87) | bar (psi) |
| Luftverbrauch | 10.8 (6.4) | m³/h (cfm) |
| Maximale Temperatur | 60 (140) | °C (°F) |
| Zylinder | 50 (1.69) | cc (oz) |
| Schallpegel | 78 | dBa |
| Empfohlener Luftdruck | 2 - 5 (29 - 72.5) | bar (psi) |
| Ausbringmenge bei 30 Doppelhüben/Min | 1.5 (0.4) | l/min (gal/mn) |
| Ausbringmenge bei 20 Doppelhüben/Min | 1.0 (0.26) | l/mn (gal/mn) |
| Materialvolumen pro Doppelhub | 50 | cc |
| Freie Ausbringmenge | 3.0 (0.78) | l/mn (gal/mn) |
| Ausbringmenge bei 15 Doppelhüben | 0.75 (0.2) | l/mn (gal/mn) |
| Luftverbrauch bei 30 Doppelhüben/Min bei 4 bar | 10.8 | m³/h (cfm) |
| Verdrängung (pro Zyklus) | 50 (3.05) | cc (cubic inch) |
| Motortyp | 500-4 | |
| Lufteinlass | F3/8" BSP / F3/8" BSP | |
| Materialauslass | F1/2" NPS / M1/2" JIC | |
| Materialeinlass | F 1/2" BSP / M26x125 | |
| Anzahl der Doppelhübe pro Liter | 20 | |
| Sealing packing upper PTFE G + Polyfluid | ♦ | |
| Höhe | 82 (32.2) | cm (in) |
| Breite | 35 (13.8) | cm (in) |
| Tiefe | 21 cm (8.3) | cm (in) |
| Materialführende Teile aus Hartchrom Edelstahl, Standard Edelsta | ♦ | |
| Gewicht | 17 (37.5) | kg (lbs) |
| Designation | Version | Fluid inlet | Section rod | Drain rod | Paint filter | Air regulator | Seal | Part number |
|---|---|---|---|---|---|---|---|---|
| 20C50 | Wall | M 26x125 | 25 mm (1'') | - | - | - | GT + PTFEG | 151770000 |
| 20C50 | Wall | M 26x125 | 25 mm (1'') | ♦ | ♦ | 2 | GT + PTFEG | 151770100 |
| 20C50 | Wall | M 26x125 | 25 mm (1'') | - | - | 2 | GT + PTFEG | 151770200 |
| Designation | Part number | ||||
|---|---|---|---|---|---|
| DRAIN ROD D16 S/S CONNECTOR 18X125 | 049596000 | ||||
| TROLLEY 2 ARMS | 051221000 | ||||
| BRACKET W. STRAPS | 056100199 | ||||
| SUCTION ROD DIAM 25 (FITTINGS 26*125) FOR EOS PUMP | 149596150 | ||||
| SCUTION ROD D25 (FITTINGS 26x125) FOR 200 L DRUM | 149596160 | ||||
| GRAVITY HOPPER 6L FOR EOS PUMP | 151140230 | ||||
| Wall mounted support for bare pump | 044910121 | ||||
| BRACKET W. STRAPS | 155580300 |
| Designation | Version | Suction rod | Pump filter | Hoses lenth (m) | Gun | Gun filter | Aircap | Tip | Part number |
|---|---|---|---|---|---|---|---|---|---|
| 20C50 + XCITE | wall | 25 mm (1'') | ♦ | 7.5 m (23 feet)) | Xcite 120 | ♦ | VX24 | - | 151260966 |
| Designation | Part number | ||||
|---|---|---|---|---|---|
| SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950091 | ||||
| SERVICING KIT FOR HYDRAULIC C50 GT | 144950096 | ||||
| PACKAGE OF SEALS FOR 500-4 AIR MOTOR | 146260990 | ||||
| SERVICING KIT FOR MOTOR 500/4 | 146260995 | ||||
| SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950090 | ||||
| SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 144950095 | ||||
| SET OF CHEVRON SEALS FOR HYDRAULIC C50 GT | 909051103 | ||||
| Ball Ø 16, 316L stainless steel | 907414142 | ||||
| Ball Ø 16, 316L stainless steel | 907414623 |
